SDG1000X Series Function/Arbitrary Waveform Generators

• Dual-channel, with bandwidth up to 60 MHz, and amplitude up to 20 Vpp
• 150 MSa/s sampling rate, 14-bit vertical resolution, and 16 kpts waveform length
• Innovative EasyPulse technology, capable of generating lower-jitter Pulse waveforms, brings a wide range and extremely high precision in pulse width and rise/fall times adjustment

Read More...

SDS2000X-E Series Super Phosphor Oscilloscopes

• 200MHz, 350MHz bandwidth models
• Real-time sampling rate up to 2 GSa/s
• The newest generation of SPO technology
• Waveform capture rate up to 110,000 wfm/s (normal mode),
• 400,000 wfm/s (sequence mode)
• Supports 256-level intensity grading and color display modes
• 7-inch TFT-LCD display and 10 one-button menus
• Record length up to 28 Mpts
• Digital trigger system
• Bode plot

Read more

SSA3000X Series Spectrum Analyzers

• All-Digital IF Technology
• Frequency Range from 9 kHz to 2.1/3.2 GHz
• -161 dBm/Hz Displayed Average Noise Level (Typ.)
• -98 dBc/Hz @10 kHz Offset Phase Noise (1 GHz, Typ.)
• Total Amplitude Accuracy < 0.7 dB
• 1 Hz Minimum Resolution Bandwidth (RBW)
• Tracking generator (TG) is currently included at no charge

Read more

SDS1000X-E Series Super Phosphor Oscilloscopes

• 100 and 200 MHz bandwidth models
• 2 or 4 analogue channels, 16 logic/MSO optional on 4 channel only
• Real-time sampling rate up to 1 GSa/s
• Math co-processor speeds front panel operation
• Waveform capture rate up to 100,000 wfm/s (normal mode), and 400,000 wfm/s (sequence mode)
• Record length up to 14 Mpts, 1 Mpt FFT
• On-screen Bode plot and web-browser control (standard on 4 channel only)
• WiFi control (optional on 4 channel only)

Read more
